Once you receive your order confirmation email, your order will be processed within 2–3 business days (excluding weekends and public holidays).
Installation must be carried out by a qualified electrician.
Ensure power is switched off before installation.
Suitable for indoor use.
The Live AGU63620 Metal Weatherproof Garage Unit is a robust, fully enclosed electrical distribution solution specifically designed for outdoor applications requiring higher current capacity, including electric vehicle charger protection. Featuring a 63A 30mA RCD and a 20A MCB in a single compact unit, it provides enhanced circuit protection for more powerful EV chargers and demanding outdoor equipment. The drop-down metal cover and robust IP65-rated metal construction ensure durability against the elements, making it ideal for garages, car charging points, workshops, and outdoor power supplies requiring 20A protection. Compliant with relevant British Standards, this unit offers professional-grade protection in a space-saving format.
IP65 Weatherproof Protection: Fully protected against water jets and dust ingress, suitable for outdoor installation.
63A 30mA RCD Included: 63A rated residual current device with 30mA sensitivity for personnel protection against electric shock.
20A MCB Included: Type B 20A miniature circuit breaker for higher-power final circuit protection (ideal for 7kW EV chargers, heavy-duty power tools, etc.).
Electric Vehicle Charger Ready: Specifically configured for higher-power EV charger circuits requiring 20A protection.
Robust Metal Construction: Fully enclosed metal body with drop-down metal cover and metal lid for maximum durability.
Drop-Down Cover Design: Hinged metal cover allows easy access while maintaining protection when closed.
Compact Dimensions: Space-saving design: 140mm (W) x 220mm (H) x 98.8mm (D).
Standard Compliant: Manufactured to BS EN 61439-3, BS EN60947-3 & BS EN61643-11 standards.
Pre-Wired Configuration: Factory-fitted RCD and MCB for quick and easy installation.
Versatile Applications: Ideal for garages, workshops, 7kW EV charging points, and outdoor power supplies.
Professional Finish: Durable powder-coated finish for corrosion resistance and long life.
| Specification | Details |
|---|---|
| Brand | Live |
| Model | AGU63620 |
| Product Type | Metal Weatherproof Garage Unit / Distribution Board |
| Enclosure Rating | IP65 (Weatherproof - dust tight and protected against water jets) |
| Enclosure Material | Fully enclosed metal construction |
| Cover Type | Drop-down metal cover with metal lid |
| RCD Rating | 63A, 30mA sensitivity |
| MCB Rating | 20A (Type B, 6kA typical) |
| Configuration | 1 RCD + 1 MCB (pre-wired) |
| Dimensions | 140mm (W) x 220mm (H) x 98.8mm (D) |
| Standards | BS EN 61439-3, BS EN60947-3, BS EN61643-11 |
| Typical Applications | 7kW EV chargers, garages, workshops, outdoor power |
| Mounting | Surface mount |
| Operating Temperature | -5°C to +40°C |
| Terminal Capacity | Suitable for standard cable sizes |
| Color | Grey (typical) |
1. What is the advantage of the 20A MCB over the 16A version for EV charging?
The 20A MCB accommodates higher-power EV chargers up to approximately 4.6kW (at 230V), making it suitable for faster charging applications where 16A would be insufficient or would operate at maximum capacity continuously.
2. Can this unit power both an EV charger and other equipment simultaneously?
This unit provides one 20A protected circuit. For multiple circuits, consider using this as a dedicated EV charger supply or consult an electrician about appropriate distribution arrangements for additional loads.
3. Is the 20A rating suitable for all home EV chargers?
Most home EV chargers range from 16A to 32A. The 20A rating is ideal for 3.6kW-4.6kW chargers. Always check your specific charger's current requirements and consult a qualified electrician for proper sizing.
4. What cable size is recommended for the 20A output circuit?
Typically 2.5mm² or 4mm² copper cable is suitable for 20A circuits, depending on cable length and installation method. The final cable size should be determined by a qualified electrician based on actual load and run length.
5. How does the IP65 rating benefit outdoor EV charger installations?
IP65 provides complete protection against water jets (e.g., rain, hose-down) and dust ingress, ensuring reliable operation in all weather conditions and making it ideal for exposed outdoor locations where standard indoor units would fail.
