Once you receive your order confirmation email, your order will be processed within 2–3 business days (excluding weekends and public holidays).
Installation must be carried out by a qualified electrician.
Ensure power is switched off before installation.
Suitable for indoor use.
The Live AGU63616 Metal Weatherproof Garage Unit is a robust, fully enclosed electrical distribution solution specifically designed for outdoor applications including electric vehicle charger protection. Featuring a 63A 30mA RCD and a 16A MCB in a single compact unit, it provides comprehensive circuit protection in a weatherproof IP65-rated metal enclosure. The drop-down metal cover and robust construction ensure durability against the elements, making it ideal for garages, car charging points, workshops, and outdoor power supplies. Compliant with relevant British Standards, this unit offers professional-grade protection in a space-saving format.
IP65 Weatherproof Protection: Fully protected against water jets and dust ingress, suitable for outdoor installation.
63A 30mA RCD Included: 63A rated residual current device with 30mA sensitivity for personnel protection against electric shock.
16A MCB Included: Type B 16A miniature circuit breaker for final circuit protection (suitable for EV chargers, power tools, etc.).
Electric Vehicle Charger Ready: Specifically designed for EV charger circuit protection with appropriate ratings.
Robust Metal Construction: Fully enclosed metal body with drop-down metal cover and metal lid for maximum durability.
Drop-Down Cover Design: Hinged metal cover allows easy access while maintaining protection when closed.
Compact Dimensions: Space-saving design: 140mm (W) x 220mm (H) x 98.8mm (D).
Standard Compliant: Manufactured to BS EN 61439-3, BS EN60947-3 & BS EN61643-11 standards.
Pre-Wired Configuration: Factory-fitted RCD and MCB for quick and easy installation.
Versatile Applications: Ideal for garages, workshops, EV charging points, and outdoor power supplies.
Professional Finish: Durable powder-coated finish for corrosion resistance and long life.
| Specification | Details |
|---|---|
| Brand | Live |
| Model | AGU63616 |
| Product Type | Metal Weatherproof Garage Unit / Distribution Board |
| Enclosure Rating | IP65 (Weatherproof - dust tight and protected against water jets) |
| Enclosure Material | Fully enclosed metal construction |
| Cover Type | Drop-down metal cover with metal lid |
| RCD Rating | 63A, 30mA sensitivity |
| MCB Rating | 16A (Type B, 6kA typical) |
| Configuration | 1 RCD + 1 MCB (pre-wired) |
| Dimensions | 140mm (W) x 220mm (H) x 98.8mm (D) |
| Standards | BS EN 61439-3, BS EN60947-3, BS EN61643-11 |
| Typical Applications | EV chargers, garages, workshops, outdoor power |
| Mounting | Surface mount |
| Operating Temperature | -5°C to +40°C |
| Terminal Capacity | Suitable for standard cable sizes |
| Color | Grey (typical) |
1. Is this garage unit specifically designed for electric vehicle charger installation?
Yes, the AGU63616 is specifically configured with a 16A MCB suitable for standard EV charger circuits, housed in an IP65 weatherproof metal enclosure ideal for outdoor charger installations.
2. What is the advantage of the drop-down metal cover design?
The drop-down cover allows easy access to RCD and MCB switches while maintaining full weatherproof protection when closed. It also provides additional security and protects against accidental impact.
3. Can this unit be used for other outdoor applications besides EV charging?
Absolutely - it's ideal for garages, workshops, garden power supplies, outdoor lighting control, sheds, and any outdoor location requiring weatherproof circuit protection with RCD safety.
4. What cable sizes are compatible with this pre-wired unit?
The terminals accommodate standard cable sizes for 16A and 63A circuits. Typically 2.5-4mm² for the 16A MCB output and 10-16mm² for the 63A RCD input/output. Always check terminal capacity before installation.
5. Is this unit compliant with UK electrical regulations for EV charger installations?
Yes, it complies with BS EN 61439-3, BS EN60947-3 & BS EN61643-11 standards and includes the required 30mA RCD protection, making it suitable for EV charger installations complying with current regulations.
