The 30W PIR Infrared Motion Sensor Outdoor Twin Security LED Flood Light is a powerful and versatile lighting solution designed to enhance security and provide convenient illumination for your outdoor spaces. Featuring two adjustable 15W LED heads (30W total), it delivers a bright 3000 lumens of crisp, cool daylight light at 6000K. The integrated PIR motion sensor boasts a wide 180° detection angle and an impressive 12-meter range, ensuring reliable activation when movement is detected. With fully adjustable controls for sensitivity (SENS), time delay (10s-5min), and ambient light threshold (LUX), you can customize the light to suit your exact needs, including setting it for day-and-night or night-only operation. Its IP65 weatherproof rating makes it suitable for all outdoor conditions, and the double-insulated design means no earth connection is required, simplifying installation. Backed by a 2-year warranty, this twin-head floodlight is an ideal choice for gardens, driveways, and perimeter security.

Key Features of 30W Twin Head PIR Floodlight

• Twin Adjustable LED Heads: Two 15W heads (30W total) can be angled independently for directional lighting.

• Bright 3000 Lumen Output: Provides ample illumination for security and visibility.

• 6000K Daylight Colour: Crisp, cool white light ideal for security and deterrence.

• Wide-Angle PIR Sensor: 180° detection angle and up to 12m range for excellent coverage.

• Fully Adjustable Controls: 3 dials for Sensitivity (SENS), Time Delay (10s-5min), and Ambient Light (LUX) for complete customization.

• Day/Night Modes: Sun position for 24/7 activation; Moon position for night-only operation.

• IP65 Weatherproof: Fully protected against dust and water jets, ideal for year-round outdoor use.

• Double Insulated (Class II): No earth connection needed, simplifying installation.

• Energy Efficient: High brightness with low power consumption.

• Wide Beam Angle: 120° beam angle for broad area coverage.

• 2 Year Warranty: Manufacturer guarantee for peace of mind.

Technical Specifications

Frequently Asked Questions (FAQs)

1. How do I adjust the PIR sensor settings on this floodlight?
The floodlight has three clearly labeled adjustment dials usually located on the sensor unit. SENS adjusts the detection sensitivity/range. TIME sets how long the light stays on after activation (10s-5min). LUX sets the ambient light level for activation (turn towards the sun symbol for day & night, towards the moon for night-only).

2. What is the benefit of having two separate adjustable heads?
The twin heads can be angled independently, allowing you to direct light over a wider area or in two different directions. This is perfect for covering corners of a building, illuminating a wide driveway, or lighting up a garden path and patio from one unit.

3. What does "Double Insulated (No Earth Needed)" mean for installation?
This means the floodlight has Class II insulation, providing an extra layer of safety without requiring a connection to the earth wire. This simplifies wiring, especially in older properties or when replacing existing fittings where an earth wire may not be present.

4. What is the difference between the Sun and Moon settings on the LUX control?
Turning the LUX dial towards the Sun symbol means the sensor will activate the light based on motion regardless of the time of day (24-hour operation). Turning it towards the Moon symbol restricts activation to night-time only, using the ambient light sensor to prevent the light from turning on during daylight.

5. How far can the PIR sensor detect movement?
The PIR sensor has an adjustable detection range of up to 12 meters, depending on the sensitivity setting (SENS dial) and environmental conditions. It also has a wide 180° detection angle, providing excellent coverage for most domestic and commercial security applications.
